C. Locate the 2nd stud 16” from either side of the 1st stud location.
Note: The distance between two studs is normally 16” (center to center).
A. Decide where to hang the Wall Cabinet.
B. Start from one side of desired location to find the 1st stud location for installing the Wall-Hanging Brackets (#8). Use a stud
finder to locate the stud and use a pencil to mark the center of the stud.
ASSEMBLY INSTRUCTIONS
(pg 7 of 12)
Ultra Heavy Duty Wall Cabinet (Model No. 20209)
Use the Installation Guide on pages 7 and 8 to secure the two Wall-Hanging Brackets (#8) to the wall. Lift the wall cabinet up
and hook its tongues (located on the back panels) over the Wall-Hanging Brackets. Assure all tongues hook securely over
both Wall-Hanging Brackets. Please refer to the pictures on pages 8 and 9.
Installation Guide for the WALL HANGING BRACKET
of the UltraHD Wall Cabinet (Model No. 20209)
Note: We recommend that the cabinet be hung such that the bottom of the cabinet rests approx. 63" above the floor.
Recommended
Height from Floor
63"
#8
#8
FLOOR
DOOR
?
?
63"
63"
