ASSEMBLY INSTRUCTIONS
(pg 6 of 12)
Ultra Heavy Duty Wall Cabinet (Model No. 20209)
Attach the Door (#7) to the unit. Line up
screw holes and tighten them using Screw
Driver (#14) and Screw B (#12).
Step 6: Install the Door (#7).
Step 7: Complete Assembled Cabinet.
a. Left Side Door (1)
b. Right Side Door (2)
#7
#12
#12
#7
