STN Bootloader
Appendix A: Firmware File Format
Firmware images to be used with STN Bootloader
are released as binary files with a .bin extension. The
STN firmware file format is detailed in this section.
The current file version is 5. If any other file version
is detected, you should abort the upload, because the
firmware will not be compatible with the file layout
described in this document. Table 11 describes STN
firmware file structure. All multi-byte values are big-
endian.
Table 11 – Firmware File Structure
Field Size (bytes) Description
Signature 6 File signature (ASCII STNFWv)
Version 2 File version (ASCII 05)
Device ID Count 1 Size of device IDs array
Device IDs Array [Dev ID Count] * 2
Device IDs of compatible devices that can
be programmed with this firmware
FW Image Descriptors Count 1
Size of firmware descriptors array (see
Table 12)
File Header
FW Image Descriptors Array [FW Image Desc Count] * 12 Optional firmware descriptors array
Firmware images, specified by firmware
image descriptors
FW Images Variable
Table 12 – Firmware Image Descriptor Format
Field Length (bytes) Description
Image Type 1 Firmware image type (see Table 13)
Reserved 1
Next firmware image to upload. 0xFF means there are no more images to
upload.
Next FW Index 1
Error FW Index 1 Firmware to upload on error. Used only for images of ‘Validation’ type.
Image Offset 4 Absolute file offset to beginning of firmware image
Image Size 4 Size of firmware image in bytes
Table 13 – Firmware Image Types
FW Image Type Value (hex) Description
Normal 00
Go to [Next FW Index] on success, handle all errors normally (ignore
[Error FW Index]
)
Go to [Next FW Index] on success; if connection is lost, reconnect,
then continue with the [Next FW Index]; if device comm error occurs,
send ResetDevice command, reconnect, then continue with the [Next
FW Index];
handle all other errors normally (ignore [Error FW
Index] )
Normal, Tolerate Errors 01
Validation 10
Go to [Next FW Index] on success, go to [Error FW Index] on
Validation error, handle all other errors normally
