4. Assemble the Left and right Pillars (EC and ED), to the cart
side panels, as shown in figure A and B.
Next, assemble the left and right pillars to the Front brace
(CN) and the Bottom shelf (EH), as shown in figure C and D.
One person should align the left side, while the second
person assembles the right side.
3. Attach the Front Brace (CN) to the Left and right cart
side panels (EA and EB).
TIP: One person should align the left side, while the
second person assembles the right side.
3
4
#6 - NO. 10x10 Screw (x4)
#6 - NO. 10x10 Screw (x8)
#7 - ø5 Lock Washer (x4)
#7 - ø5 Lock Washer (x8)
#8 - ø5 Washer (x4)
#8 - ø5 Washer (x8)
ASSEMBLY INSTRUCTIONS
EB
CN
EA
EC
Back view
7
A.
B. C.
D.
