Centro 6800 User Manual

Page 11

Back view

7. Attach the upper back panel (CO) to both the left

and right side panels (EA and EB).

Only install hardware in the bottom portion of the

back panel, as shown in figure B.

8b. Assemble the towel bar ( DL ) to the right side shelf

table (DJ) as shown in figure B.

8a. Attach the right side shelf fascia(DK) to the right side

shelf table (DJ), as shown in figure A.

#4 - ø7 Lock Washer (x4)

#6 - NO. 10x10 Screw (x3)

#1 - ¼”×38mm Screw (x2)

#5 - ø7 Washer (x4)

#7 - ø5 Lock Washer (x3)

#4 - ø7 Lock Washer (x2)

#3 - ¼” x 13mm Screw (x4)

#8 - ø5 Washer (x3)

#5 - ø7 Washer (x2)

ASSEMBLY INSTRUCTIONS
