7093KL, KR, KT _ _
AFTER YEARS OF USE, IMPURITIES AND LIME SCALE CAN RESTRICT THE
WATER FLOW.
M a i n t e n a n c e
Please follow these instructions to clean the cartridge:
Remove the dial cap, screw, and
dial.
Remove remaining assembly by
carefully applying a plumber’s
wrench to the outside of the sleeve
and turn counter-clockwise.
Remove nut from sleeve and then
remove the plates from the wall.
Shut off the water line by turning the check valve shut off mechanism
clockwise. Make sure that both hot and cold sides are closed.
Gently remove the cartridge using a 24MM wrench or an adjustable
wrench.
of white vinegar/water until all dirt is dissolved.
Oil the O-rings with vegetable oil and wipe the housing with a wet
cloth before reassembling.
Carefully reassemble the cartridge.
installation and proper positioning of the thermostatic settings).
Check valve shut-off
Temperature
Limiter
Cartridge Cleaning
