7093KL, KR, KT _ _
IMPORTANT: Do not turn control spindle. Accidentally turning the
control spindle will change the temperature setting, which is
pre-callibrated from the factor y.
Remove plastic mud guard.
Completely screw the sleeve onto the valve until it bottoms out. Firmly
tighten by hand.
Remove outer layer of the adhesive strip on back of the plate and
slide plate over sleeve without adhering it to the wall.
Screw the nut onto the sleeve just enough to pull the plate back over
the nut. This will make sure that the plate is centered over nut before
adhering it the wall.
Tighten the nut down completely, which will secure the plate to the
get the best seal.
Press the dial onto the control spindle with the 12 oclock position
being exactly between the H (hot) and C (cold) markings. Insert screw
Do not overtighten.
Install the handle with the allen screw hole facing upwards. Firmly
tighten down the allen screw with the allen wrench.
Tr i m
Trim Installation (1)
