Technical Specifications

DA-10382-00A-010 — 06.12.2000

Compaq Armada M700

System Unit

Dimensions (HxWxD)

12.4 x 9.8 x 1.1 in/31.4 x 24.9 x 2.8 cm

Weight

700 MHz/14-in display/weight saver

5.1 lbs/2.3 kg

650 MHz/14–in display/weight saver

5.1 lbs/2.3 kg

500 MHz/14–in display/weight saver

5.1 lbs/2.3 kg

450 MHz/13-in display/weight saver

4.8 lbs/2.2 kg

400 MHz/14–in display/weight saver

5.1 lbs/2.3 kg

366 MHz/13-in display/weight saver

4.8 lbs/2.2 kg

Stand-Alone Power Requirements

Nominal Operating Voltage (Li-Ion)

14.4V (8-cell), 10.8V (6-cell)

Average Operating Power

15W

Peak Operating Power

30W

Power Supply

Rated Input Voltage

90 to 264 VAC (auto-switching)

Rated Input Current

< 60W

Rated Frequency

47 to 63 Hz

Temperature

Operating

50° to 95°F/10° to 35°C

Non-operating

–4° to 140°F /–20° to 60°C

Relative Humidity (non-condensing)

Operating

10% to 90% relative humidity, non-condensing

Non-operating

5% to 95% relative humidity, 101.6°F/38.7°C Maximum
wetbulb temperature

Shock

Operating

10 G, 11 ms, half-sine

Non-operating

60 G, 11 ms, half-sine

Vibration

Operating

0.5 G zero-to-peak, 10 to 500 Hz, 0.25 oct/min sweep

rate

Non-operating

1.0 G, zero-to-peak, 10 to 500 Hz, 0.5 oct/min sweep

rate

Maximum Altitude (unpressurized)

Operating

0-10,000 ft/(0 to 3,048 m)

Non-operating

0-30,000 ft/(0 to 9,144 m)

Dimensions (HxW)

11.22 x 8.46 in/28.5 x 21.5 cm

14.1-Inch Color TFT
XGA Display

Diagonal Size

14.1 in/35.81 cm

Mounting

Internal Panel Supports, Side Mounted

Number of Colors

Up to 16.8M

Contrast Ratio

150:1

Brightness

120nt typ

Pixel Resolution

Pitch

0.264 x 0.264 mm

Format

1024 x 768

Configuration

RGB stripe

Backlight

Edge Lit

Character Display

80 x 25

Total Power Consumption

4.2W
