Technical specifications, Uick, Pecs – Compaq M300 User Manual

Page 17: Compaq armada m300

UICK

PECS

Technical Specifications

DA-10381-00A-010 — 06.12.2000

Compaq Armada M300

System Unit

Dimensions (HxWxD)

0.89 x 10.4 x 9 in/2.3 x 26.4 x 22.9 cm

Weight

333-MHz processor

3.18 lbs to 3.37 lbs/1.44 kg to 1.53 kg

Stand-Alone Power Requirements

Nominal Operating Voltage (Li-Ion)

14.2 VDC

Nominal Operating Voltage (NiMH)

9.6

Maximum Operating Power

35W

Peak Operating Power

40W

Temperature

Operating

50° to 95°F/10° to 35°C

Non-operating

–4° to 140°F/–20° to 60°C

Relative Humidity (non-condensing)

Operating

10% to 90% relative humidity, non-condensing

Non-operating

5% to 90% relative humidity, 101.6°F/38.7°C Maximum
wet bulb temperature

Shock

Operating

10 G, 11 ms, half-sine

Non-operating

60 G, 11 ms, half-sine

Vibration

Operating

0.5 G, 10 to 500 Hz, 0.5 Oct/Min sweep rate

Non-operating

1.0 G, 10 to 500 Hz, 0.5 Oct/Min sweep rate

Maximum Altitude (unpressurized)

Operating

0-10,000 ft/3,048 m (14.7 to 10.1 psia)

Non-operating

0-30,000 ft/9,144 m (14.7 to 4.4 psia)

Dimensions (HxW)

7.5 x 10.1 in/19 x 25.6 cm

11.3-Inch Color TFT
SVGA or XGA Display

Diagonal Size

11.3 in/28.7 cm

Mounting

Internal

Number of Colors

16M

Contrast Ratio

125:1

Brightness

120 to 150 nit AC only/80 on battery

Pixel Resolution

Pitch

0.264 x 0.264 mm

Format

800 x 600

Configuration

RGB Stripe

Backlight

CCFT

Character Display

80 x 25

Total Power Consumption

Refresh

640 x 480, 800 x 600, 1024 x 768, 1280 x 1024, 1600 x

1200
