TECHNICAL DATA
The following shows the technical data for RED Focus.
Dimensions Length: 6.5” (165.1 mm)
Diameter: 2.75” (69.85 mm)
Weight TBD lbs (TBD kg)
Environment No exposure to heat
No exposure to vibration
No exposure to strong electric or magnetic fields
Operating Temperature Maximum: 50 - 104°F (10 - 40 °C)
Humidity Operating: 20 - 80 %, non-condensing
Non-Operating: 10 - 90 %, non-condensing
Air Dust-Free
Power 5V DC, 5A
TROUBLESHOOTING
For errors or issues beyond those listed below, please contact support through our web site at
www.red.com/support .
• RED FOCUS Does Not Power Up - Verify batteries are installed correctly - reinstall if necessary. If
batteries are installed correctly, replace batteries with fresh ones.
• RED FOCUS Image Is Blurry After Tightening Focus Ring Bolts (RED ONE) - Some shifting may
occur while tightening the focus ring, recheck the back focus again and adjust as necessary.
