PS Engineering
MB10 Marker Beacon Receiver and Indicator System
Installation and Operator’s Manual
200-023-0001 Appendix B Rev. 9, Sept. 2013
Appendix B, J10 Interconnect
1A
11-33 VDC 1
9
MB10 Sub-D DB-15 Male
Power In
Aircraft Ground
NOTES: 1. Use EITHER active High OR Active Low output.
See Section 2.4.5 for details
2. For remote Marker Mode control.
Use ON-OFF-MOM switch. See Section 2.5.6
2
10
5
14 V Dimmer Input
28 V Dimmer Input
White Lamp Output Active Hi
White Lamp Active Low
Remote Marker Indicator
3
11
Amber Lamp Output Active High
Amber Lamp Ground Active Low
4
12
Blue Lamp Output Active High
Blue Lamp Active Low
Middle Marker Sense Output
Flight Control System
6
14
Marker Audio Hi
Marker Audio Lo
Audio System
7
8
Note 1
13
15
Remote Test/Mute
Remote Hi Sense
Note 2
Female BNC
on unit
MKR Ant.
