PS Engineering PMA8000C Installation Manual - Manual (Page 7)

PS Engineering
PMA8000C Audio Selector Panel and Intercom System
Installation and Operator’s Manual
200-890-0303 Page 1-4 Rev. 3, May 2014
1.6 EQUIPMENT SUPPLIED
1 ea. of the following units:
Model Description Part Number
PMA8000C PMA8000C Audio Panel with Marker, Stereo Intercom, and Bluetooth
connectivity, supporting three communications transceivers. 050-890-0303
PMA8000C Same as -0303, but with expansion capability for 12 passengers. 050-890-0313
PMA8000C Installation Kit: 250-890-0000
Description Quantity Part
Number
Installation rack assembly 1 430-890-0040
Rack back plate 1 430-890-0050
44-pin connector kit 2 120-891-2045
Backshell, connector 2 625-025-2465
Hood Retaining Blocks 2 431-891-0100
4 40 X 7/16 screw w/nylon patch 4 475-440-0007
4 40 X 3/8 screw w/nylon patch 4 475-440-1038
4-40 x ¼” screw with lock washer 2 475-440-0001
Grounding Solder Lug 2 475-009-0001
Cable Clamp 1 625-001-0002
#6-32 x ½” Flat head Philips screw 6 475-632-0012
#6-32 Clip Nut 6 475-630-0002
1.7 EQUIPMENT REQUIRED BUT NOT SUPPLIED
a. Circuit Breaker: 1 ea; 5 amp PULL TYPE REQUIRED for PMA8000C
b. Speaker, 4

c. Headphone Jacks (Stereo, as Required)
d. Microphone Jacks (as Required)
e. Headphones, 150
 (Stereo), up to 6 as required
f. Microphones, up to 6 as required
g. Marker Antenna (75 MHz, VSWR <1:1.5, and appropriate for the airspeed)
h. Interconnect Wiring
1.8 OPTIONAL ITEMS
a. Music Patch Cord, 3.5mm to 2.5mm, PS Part Number 425-006-2535
1.9 LICENSE REQUIREMENTS
None
PMA8000C (050-890-0303, -0313) Bluetooth™ Radio approval:

FCC ID: QOQWT32AE

Industry Canada ID: 5123A-BGTWT32AE

CE EMC Directive 89/336/EEC as amended by Directives 92/31/EEC and 93/68/EEC
