PMA8000C Audio Selector Panel and Intercom System
Installation and Operator’s Manual
200-890-0303
Page 1-3
Rev. 3, May 2014
Audio Selector Specifications
Audio selector panel input impedance:
510
Input Isolation:
-60 dB (min.)
Speaker Muting:
-60 dB (min.)
Speaker Output (into 4
) with no clipping
14 VDC:
28 VDC:
3 Watts (min.)
10 Watts (min.)
Receiver Inputs:
9 (COM 1, COM 2, COM 3, NAV 1, NAV 2, ADF,
DME, MKR, AUX)
Unswitched Inputs:
5 (including front jack)
Transmitter Selections:
6 (COM 1, COM 2, COM 3
Com1/2 COM 1/3, COM 2/3)
Speaker Impedance:
4
Headphone Impedance:
150 – 1000
Headphone Output:
38 mW each headset, no clipping <1% THD typical
Microphone Impedance:
150 - 600
Bluetooth Radio (PMA8000C -0303 only)
Class 3, FCC ID QOQWT32AE
Intercom Specifications
Intercom Positions:
6 places (with individual IntelliVox® circuits)
Up to 12 places with -0313 and 11636R expansion units
Music Inputs:
2, (Independent, Stereo)
Music Muting:
>-30 dB "Soft Mute" when COM or intercom active.
Distortion:
<1% THD @ 38 mW into 150
Mic Freq. Response, 3 dB:
300 Hz - 6000 Hz
Music Freq. Response, 3 dB:
10 Hz – 26 kHz
MARKER BEACON RECEIVER:
Frequency:
75 MHz Crystal Controlled
Sensitivity:
Low:
High:
Capable of: (preset at factory for field application)
1000
Volts (Hard) (360 to 570 V soft)
200
Volts (Hard) (130 to 200 V soft)
Selectivity:
-6 dB at ±10 kHz
-40 dB at ±120 kHz
External Lamp Output:
7.5 (±4 VDC unloaded, at maximum brightness) VDC
positive when active, max. current 125 mA
MM Sense:
Active high (4.5 ± 1.0VDC)
