CREATIVE DSI V.92 User Manual
Page 32
Installing and Testing Modem Drivers 3-16
10.When the dialog box similar to Figure 3-23
appears, click the
Show compatible
hardware option to select it, and then click
ESS ES56T-PI Data Fax Modem in the
Models box.
11.Click the
Have Disk button.
12.When the dialog box similar to Figure 3-24
appears, click the
Browse button to locate
the driver files in
E:\Drivers\WinXP
(where E: represents your CD-ROM Drive),
and then click the
OK button.
13.In the Hardware dialog box that appears,
click the
Show compatible hardware
option to select it, and then click
Broadxent
DSI V.92 PCI DI3631 in the Models box.
14.Click the
Next button.
Figure 3-23
After you have set up your
modem, run a test to ensure
that your card has been
installed properly (see
Figure 3-24
