About Your Modem 1-1
About Your Modem
This chapter helps you locate and identify the components of your modem.
Jacks
Jacks are one-hole connecting interfaces on your modem card. They allow you to
attach other devices to your card. The jacks on your modem card can be seen in
Figure 1-1.
• Place the modem in front of
you as you go through this
chapter. This will help you
identify the various
components on your card.
• If you encounter a hardware
conflict while connecting a
Plug and Play device, refer to
Table A-1 on page A-1 for a
list of available Plug and Play
resources.
Figure 1-1 The jacks on your modem card.
Telephone Line Jack
The Telephone Line jack allows
you to connect to a telephone
line for data transmission and
document faxing.
Rear Panel
Phone Jack
The Phone jack allows you to
connect a telephone to the
card. This jack may differ in
certain countries.
