PRG Node Plus - Manual (Page 23)

PRG NODE PLUS USER MANUAL 21
SPECIFICATIONS
Technical Specifications
POWER REQUIREMENT: 90 to 264 VAC, 47 to 63 Hz
Draws less than 60 watts continuously.
COOLING: Convection.
OPERATING TEMP: -20°C to 50°C (-4°F to 122°F).
INPUT: One control signal input which is fed from a console providing either Virtuoso or DMX-
over-Ethernet (Art-Net) protocol.
OUTPUT: One Art-Net output carrying up to six DMX512 universes.
Six (non-isolated) standard DMX512 serial outputs, each carrying one DMX512 universe.
(Both output protocols are simultaneously active in Virtuoso mode.)
COMM INDICATORS: Input and output status LEDs indicating DMX Tx, RDM Tx and RDM Rx data (DMX ports),
and Link, Tx data and Rx data (Ethernet ports).
POWER INDICATOR: Green LED indicating that DC power has been applied.
CONTROL: Built-in Menu Display with joystick and button controls.
HOUSING: Standard 1U 19" rack mount chassis.
WEIGHT: 4.5 lbs (2.04 kg)
COMPLIANCE: ETL and CSA Standards in CE and DENAN category B, Circle PSE.
1.72"
(44 mm)
