MBOX
®
MEDIA SERVER USER MANUAL
155
Shutter Control
Chan
Size
Function
Default Snap
1
1
0
Y
2
2
Shutter X
32767
N
4
2
Shutter Y
32767
N
6
1
Red
0
N
7
1
Green
0
N
8
1
Blue
0
N
9
2
Shutter Scale
65535
N
11
1
Shutter Edge
0
N
12
1
Shutter 1a
0
N
13
1
Shutter 1b
0
N
14
1
Shutter 2a
0
N
15
1
Shutter 2b
0
N
16
1
Shutter 3a
0
N
17
1
Shutter 3b
0
N
18
1
Shutter 4a
0
N
19
1
Shutter 4b
0
N
20
1
Shutter Rotation
127
N
20
Total Channels
Shutter Shape
Values
Shape
Notes
0-9
Disabled
10-19
Moving
Light Mode
Separate controls for each end of
shutter. If both controls are zero,
shutter disappears.
20-29
Leko Mode
Distance and angle controls. If
distance is zero, shutter disappears.
30-39
Iris Mode
A round iris, scale is magnified to
enclose the screen. No other controls.
40-49
"Blob"
Mode
A Bezier curve is drawn touching the
midpoints of the rectangle formed by
Leko Mode.
Keystone Control
Chan
Size
Function
Default
Snap
1
1
255
Y
2
2
Keystone X
32767
N
4
2
Keystone Y
32767
N
6
1
0
Y
7
1
Tile Overlap
0
N
8
2
Scale
65535
N
10
1
Edge 1
0
N
11
1
Edge 2
0
N
12
1
Edge 3
0
N
13
1
Edge 4
0
N
14
1
Corner 1 - X
0
N
15
1
Corner 1- Y
0
N
16
1
Corner 2 - X
0
N
17
1
Corner 2 - Y
0
N
18
1
Corner 3 - X
0
N
19
1
Corner 3 - Y
0
N
20
1
Corner 4 - X
0
N
21
1
Corner 4 - Y
0
N
22
1
Keystone Rotation
127
N
22
Total Channels
Edge Blending Mode
Values
Mode
Curve
0-9
Eighth Order
Steep
10-19
Fourth Order
Medium
20+
Second Order
Shallow
