Channel – PRG Mbox Designer User Manual v3.6.1 User Manual
Page 162
154
MBOX
®
MEDIA SERVER USER MANUAL
*
Special commands require that the value be held for three
seconds, followed by an immediate change to 0 (without
any other values in between).
** When the control channel stays at this value for three sec-
onds, the Camera Fog and Blur controls are mapped to
Blend and Overlap respectively. These controls are used to
make changes to the blend for use with the Wide Pan-
oramic mode.
Ambient and Spot Lights
Chan
Size
Function
Default
Snap
1
1
Intensity
0
N
2
1
Red
255
N
3
1
Green
255
N
4
1
Blue
255
N
4
Total Channels
Camera Control
Chan
Size
Function
Default
Snap
1
1
Effect 1
(see
0
Y
2
1
Effect Control 1a
0
N
3
1
Effect Control 1b
0
N
4
1
Effect 2
(see
0
Y
5
1
Effect Control 2a
0
N
6
1
Effect Control 2b
0
N
7
1
Intensity
255
N
8
1
Red
255
N
9
1
Green
255
N
10
1
Blue
255
N
11
2
Orbit X
32767
N
13
2
Orbit Y
32767
N
15
2
Dolly
32767
N
17
2
Roll
32767
N
19
1
Spin
127
N
20
2
Field of View
32767
N
22
2
Pitch
32767
N
24
2
Yaw
32767
N
26
1
0
Y
27
1
Decay
0
N
28
1
Fog
0
N
29
1
Shutter Dampening
0
N
30
1
Pix Map Level
255
N
31
1
0
Y
32
1
Audio Volume
255
N
32
Total Channels
Pixelmapping Control Channel
Values
Command
0
Enable All
254
Disable Masked
255
Disable All
Control Channel
Values
Play Mode
10-19
Version HUD
20-29
Performance HUD
30-39
FPS Display
40-44
Lights/Camera/Shutter/Keystone for Main
Screen or Left Screen in Dual Independent (Ind)
Mode (Art-Net Input A)
45-49
Lights/Camera/Shutter/Keystone for Right
Screen (Art-Net Input B)
50-54
Texture Information for Layers 1-6 or Left Screen
in Dual Ind Mode (Art-Net Input A)
55-59
Texture Information for Layers 7-12 or Right
Screen in Dual Ind Mode (Art-Net Input B)
60-64
Object Information for Layers 1-6 or Left Screen
in Dual Ind Mode (Art-Net Input A)
65-69
Object Information for Layers 7-12 or Right
Screen in Dual Ind Mode (Art-Net Input B)
70-74
Raw Art-Net HUD for input A
75-79
Raw Art-Net HUD for input B
80-84
Show pix-map context view
85-89
Show pix-map fixture view
90-94
Show alignment rectangles
(no longer used - see channels 120-139 below)
95-99
Show alignment rectangles with circle & X
100 - 109
Show pix-map sample areas
110 - 119
Timecode HUD
120-139
Show alignment rectangles (new)
220
Cancel keyboard HUD *
230
File Sharing On *
231
File Sharing Off *
232
ARD On *
233
ARD Off *
240
Rescan Media Library *
242
Enable Blend and Overlap controls **
250
Quit Application *
251
Shutdown Computer *
252
Restart Computer *
253
Restart Application *
