Page 14 For technical questions, please call 1-800-444-3353. Item 67616
parts list and Diagram
plEaSE REaD thE FOllOWinG CaREFullY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR ExPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
parts list
Record product’s Serial number here:
note: If product has no serial number, record month and year of purchase instead.
note: Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
part Description Qty
1 Depth Gauge 1
2 Clamping Band 1
3 Hex Bolt (M8x110) 1
4 Auxiliary Handle 1
5 Hex Nut (M8) 1
6 Left Head Screw (M6x22) 1
7 Drill Chuck 1
8 Spindle 1
9 Tapping Screw (ST4x22) 4
10 Spring (Ø18.2x9) 1
11 Gear Box 1
12 Flat Washer (Ø29) 2
13 Felt Ring (Ø29xØ18x7.4) 1
14 Bearing Bush 1
15 Ball Bearing (6002.2RS) 1
16 Circlip For Hole (Ø32) 1
17 Circlip For Shaft (Ø15) 1
18 Key (3x3.7x10) 1
19 Gear 1
20 Circlip For Shaft (Ø10) 1
21 Mode Switch 1
22 Mode Switch Support 1
23 Mode Washer 1
24 Tapping Screw (ST4x12F) 1
25 Gear Box Cover 1
26 Needle Bearing (HK081210) 1
27 Impact Block 1
part Description Qty
28 Flat Washer (Ø4) 3
29 Spring Washer (Ø4) 3
30 Screw (M4x14) 2
31 Screw (M4x12) 1
32 Ball Bearing (608.2RS) 1
33 Circlip For Hole (Ø22) 1
34 Armature 1
35 Ball Bearing (608.2z) 1
36 Bushing 1
37 Label 1
38 Housing Support 1
39 Tapping Screw (ST4x18F) 6
40 Stator 1
41 Rubber Pin 1
42 Switch 1
43 Carbon Brush, Brush Holder 2
47 Label 1
48 Housing Cover 1
49 Tapping Screw (ST4x14C) 2
50 Cord Clamp 1
51 Key Sleeve 1
52 Chuck Key 1
53 Power Cord 1
54 Forward/Reverse Switch 1
55 Trigger 1
56 Lock Button 1
