Dip switch, For edid/audio – Cable Electronics HSW44C User Manual
Page 8
7
SW1-SW4
for EDID/Audio
Note
1
If the HDTV shows video but without audio, please try to set audio mode to stereo.
2
Factory default of SW1-SW4: Pin#1-OFF [ ] & Pin#2- OFF [ ] for 1080p with stereo.
3
If you encounter any unsolved audio/video output problem during system installation, please
turn any SW1-SW4 to Pin#1-OFF[ ] & Pin#1-ON[ ], for safe mode to enforce the most
compatible 720p stereo output for system check. However, the safe mode cannot be initiated if
your HDMI source is set to enforce 1080p output. In this case, please reconfigure your HDMI
source to all resolution output for troubleshooting.
4
Bypass means the matrix will maintain playing the original format of HDMI signals in video
and perhaps audio. By setting at this mode, the users may encounter compatibility issue
among different kinds of HDMI sources and displays. If you cannot get the audio and/or
video output normally at the system installation, please change the DIP switch setting to
default mode or even safe mode to verify the functionality of the device.
5
Set Pin#1 at ON[ ] first then connect the HDMI Input to HDTV through a HDMI cable. Wait
for 20 seconds. The EDID learning procedure will be finished. If you want to learn the EDID
from another HDTV, you must set Pin#1 at OFF[ ] first and repeat this procedure.
DIP Switch Position
Video
Audio
Description
Pin#1
Pin#2
OFF
[ ] OFF [ ]
Up to
1080p
Stereo
1
Default Mode
2
– Up to 1080p & stereo audio output for most
HDTVs
OFF
[ ]
ON
[ ]
Up to 720p
/ 1080i
Stereo
Safe Mode
3
–
Enforce the system output at 720p/1080i video
and stereo audio for basic compatibility among HDTVs
ON
[ ]
OFF
[ ]
Bypass
4
Bypass
4
EDID Learning Mode
5
– for learning EDID from the display
while playing any received HDMI audio format
ON
[ ]
ON
[ ]
Bypass
Stereo
EDID Learning & Stereo Mode
5
– for learning EDID from the
display while enforcing stereo output if any HDTV cannot play
surround sound normally
DIP Switch
