3
Features
State-of-the-art Silicon Image (founder of HDMI) chipset embedded for upmost compatibility and reliability
HDMI 1.2a/1.3c* compliant
HDCP compliant
Allows any source to be displayed on multiple displays at the same time
Allows any HDMI display to view any HDMI source at any time
Supports 7.1 channel digital audio
Supports default HDMI EDID and learns the EDID of displays
The matrix master can switch every output channels to any HDMI inputs by push button, IR remote control,
or RS-232 control
Allows controlling local HDMI sources such as DVD and TiVo by IR extender through control path at remote
receiver
Allows to control main matrix center through control line at remote receiver
Extends video signal up to 115 feet (35m) over CAT5e at 1080p
Easy installation with rack-mounting and wall-mounting designs for master and receiver respectively
Specifications & Package Contents
Model Name HSW44C v1.2 / HSW44C v1.3
Technical HSW44C HSMR
Role of usage 4x4 matrix switch & transmitter [TX] Receiver [RX]
HDMI compliance [HSW44C v1.2] – HDMI 1.2a [HSW44C v1.3] – HDMI 1.3c
HDCP compliance Yes
Video bandwidth
[HSW44C v1.2] – Single-link 165MHz [4.95Gbps]
[HSW44C v1.3] – Single-link 340MHz [6.75Gbps]
Video support 480i / 480p / 720p / 1080i / 1080p60
Audio support Surround sound (up to 7.1ch) or stereo digital audio
Transmission
Full HD (1080p): 115ft (35m) [CAT5e] / 130ft (40m) [CAT6]
HD (720p/1080i): 165ft (50m) [CAT5e] / 180ft (55m) [CAT6]
Equalization N/A 8-level digital control
Input TMDS signal 1.2 Volts [peak-to-peak]
Input DDC signal 5 Volts [peak-to-peak, TTL]
ESD protection
[1] Human body model — ±15kV [air-gap discharge] & ±8kV [contact discharge]
[2] Core chipset — ±8kV
* HDMI 1.2a for HSW44C v1.2
HDMI 1.3c for HSW44C v1.3
