Pilot 575 Manual_ Last Revision_En.doc 2/22
SAFE USAGE OF THE PROJECTOR 3
INSTALLING THE PROJECTOR 4
FITTING THE LAMP 4
POWER SUPPLY – MAINS 5
CONTROL CONNECTIONS 5
DMX TERMINATOR 6
SETUP OPTIONS-PROJECTOR CONFIGURATION 6
TO SET THE DMX START ADDRESS 6
FUNCTIONS DISPLAY 7
REPLACING GOBOS 9
REPLACING BELTS 9
DMX CONTROL CHANNEL FUNCTIONS 10
MAINTENANCE 15
LUBRICATION 15
KEEPING THE PROJECTOR CLEAN 15
TROUBLESHOOTING 15
TECHNICAL DATA 17
ELECTRICAL DIAGRAM 19
COMPONENT ORDER CODES 20
CHANGING THE OPERATION FREQUENCY 21
Please note that as part of our ongoing commitment to continuous product development, specifications are subject to change
without notice. Whilst every care is taken in the preparation of this manual we reserve the right to change specifications in the
course of product improvement. The publishers cannot be held responsible for the accuracy of the information herein, or any
consequence arising from them.
Every apparatus is tested completely and packed properly by the manufacturer. Please make sure the packing and/or the
apparatus are in good condition before your installation and use. Should there be any damage caused by transportation, consult
your dealer and do not use the apparatus. But any damage caused by improper use will not be assumed by the manufacturer
and/or dealer.
THESE ITEMS ARE PACKED TOGETHER WITH THE PROJECTOR
G clamps (2 PCS)
3-pin XLR plug (1 PCS); 3-pin XLR socket (1 PCS)
Safety cords (2 PCS)
Spare glass gobos (3 PCS)
This manual (1 PCS)
clamps (Options) (2PCS)
Thank you for purchasing our product PILOT 575, PR-2575.
This product manual contains important information about the safe installation and use of this projector.
Please read and follow these instructions carefully and keep this manual in a safe place for future
reference.
PILOT 575 is an innovative projector with an elegant housing, which is of Pan’ s and Tilt’ s locks for
maintenance and high quality fans free from noise. The projector has 2 types of clamps for mounting
at any direction and position. Which complies to CE norms and standards and uses international
protocol DMX 512.
The projector uses MSR575 discharge lamp and high quality optical system, which produces bright
and beautiful light beam and has 60% output lumen more than the similar products with the same
power consumption. The projector features effects of strobe, frost light, mixed colours and rainbow, so
it is suitable for applications in TV station, disc, singing and dancing stage, nightclub, etc.
ACCESSORIES
INDEX
INTRODUCTION
