Pilot 575 Manual_ Last Revision_En.doc 12/22
017-024 White/colour filter 1
025-032 Colour filter 1
033-040 Colour filter 1/colour filter 2
041-048 Colour filter 2
049-056 Colour filter 2/colour filter 3
057-064 Colour filter 3
065-072 Colour filter 3/colour filter 4
073-080 Colour filter 4
081-088 Colour filter 4/colour filter 5
089-096 Colour filter 5
097-104 Colour filter 5/colour filter 6
105-112 Colour filter 6
113-120 Colour filter 6/white
121-127 White
128-133 Clockwise rotation in speed 1
134-139 Clockwise rotation in speed 2
140-145 Clockwise rotation in speed 3
146-151 Clockwise rotation in speed 4
152-157 Clockwise rotation in speed 5
158-163 Clockwise rotation in speed 6
164-169 Clockwise rotation in speed 7
170-175 Clockwise rotation in speed 8
176-181 Clockwise rotation in speed 9
182-187 Clockwise rotation in speed 10
188-195 Stop rotating
196-201 Anti-clockwise rotation in speed 1
202-207 Anti-clockwise rotation in speed 2
208-213 Anti-clockwise rotation in speed 3
214-219 Anti-clockwise rotation in speed 4
220-225 Anti-clockwise rotation in speed 5
226-231 Anti-clockwise rotation in speed 6
232-237 Anti-clockwise rotation in speed 7
238-243 Anti-clockwise rotation in speed 8
244-249 Anti-clockwise rotation in speed 9
Colour Wheel
2
250-255 Anti-clockwise rotation in speed 10
000-043 Clear
044-085 Gobo 1
086-128 Gobo 2
129-170 Gobo 3
171-212 Gobo 4
11
Rotating
Gobo Wheel
213-255 Gobo 5
000-120 (Rotating gobo) 0~540 º index
121-127 (Rotating gobo) clockwise rotation in speed 1
128-135 (Rotating gobo) clockwise rotation in speed 2
136-143 (Rotating gobo) clockwise rotation in speed 3
144-151 (Rotating gobo) clockwise rotation in speed 4
12 Gobo
Rotation
152-159 (Rotating gobo) clockwise rotation in speed 5
