INDEX
SECTION PAGE
SAFE USAGE OF THE PROJECTOR 3
INSTALLING THE PROJECTOR 4
FITTING THE LAMP 4
POWER SUPPLY – MAINS 5
CONTROL CONNECTIONS 5
SETUP OPTIONS – PROJECTOR CONFIGURATION 6
DMX START ADDRESS 6
DMX CONTROL CHANNEL FUNCTIONS 7
STAND – ALONE MODE 7
MASTER/SLAVE SYNCHRO MODE 8
MAINTENANCE 8
KEEPING THE PROJECTOR CLEAN 9
LUBRIFICATION 8
CHANGING THE GOBOS 9
TROUBLESHOOTING 9
TECHNICAL DATA 10
ELECTRICAL DIAGRAM 11
COMPONENT ORDER CODES 12
Please note that as part of our ongoing commitment to continuous product development, specifications are subject to change without notice.
Whilst every care is taken in the preparation of this manual we reserve the right to change specifications in the course of product improvement.
The publishers cannot be held responsible for the accuracy of the information herein, or any consequence arising from them.
Every apparatus is tested completely and packed properly by the manufacturer. Please make sure the packing and / or the apparatus is in
good condition before your installation and use. Should there be any damage caused by transportation, consult your dealer and do not use the
apparatus. But any damage caused by improper use
will not be assumed by the manufacturer and / or dealer.
ACCESSORIES
THESE ITEMS ARE PACKED TOGETHER WITH THE PROJECTOR
Mounting Bracket (1 PCS)
M8x25 for mounting bracket (2 PCS)
Power-cord (1 PCS)
XLR plug (1 PCS)
XLR socket (1 PCS)
Safety cord (1 PCS)
Spare gobos (4 PCS)
This manual (1 PCS)
INTRODUCTION
Thank you for purchasing our PILOT 150 PR-2150.
This product manual contains important information about the safe installation and use of this projector. Please
read and follow these instructions carefully and keep this manual in a safe place for future reference.
The PILOT 150 is an innovative projector with an elegant housing, which is made from high intensity and heat–
resistant complex plastic. PILOT 150 compiles to CE norms and standards and uses international control
protocol DMX 512. The projector may also be used as a stand-alone unit, master/slave synchro mode or
controller mode if desired, controlled by sound, and/or automatic internal programmes, so it is suitable for many
different applications.
PILOT 150 features 9 dichroic colours, 7 interchangeable rotating gobos, and an independent adjustable
strobe/shutter. It can be setup easily via the touch-switches and digital display screen.
2/14 pilot 150 manual.doc
