To ensure the reliability of the projector it should be kept clean. It is recommended that the fans
should be cleaned every 15 days. The dichroic colour filters should also be regularly cleaned to
maintain an optimum light output. Do NOT use any type of solvent on dichroic colour filters.
Cleaning frequency depends on the environment in which the fixture operates: damp, smoke or
particularly dirty surroundings can cause greater accumulation of dirt on the unit’
s optics. A soft
cloth and typical glass cleaning products should be used in cleaning.
Do not use any organic solvent, e.g. alcohol, to clean the housing of the
projector.
PROBLEM RESOURCE
The projector does not start Check that the fuse is not blown.
Check that the lamp is ok.
The projector switches on but does not
answer to commands Check the XLR cable is good.
The projector only functions
intermittently Check the fans are working and not dirty.
The beam appears dim Check the lamp is not at the end of its life.
Power supply: 230V AC 50Hz
Optional: 200V, 220V, 240V AC 50/60Hz
Power consumption: 1500W at 220V
Lamp: HMI 1200W, double ends
Colours: 7 didichroic colours + white
Rainbow effect at variable speeds
Frost: 1 frost filter
CTC filters: 2 Colour temperature correction filters, 3200°K and 6000°K
Iris: Continuously variable low noise iris
Colour temperature: Normal 5600°K, adjustable high 6000°K and low 3200°K
Shutter/strobe: 2 Blade shutter for dimming, blackout and strobe 1-7 F.P.S.
Control operation: Stand-alone mode, synchro mode
Protocol: Standard DMX 512
DMX channels: 4 channels, suppled with dedicated manual controller
Beam angle: 12°
Dimensions: 900mm LONG x 330mm WIDE x 230mm HIGH
Including controller and bracket:
1250mm LONG x 500mm WIDE x 330mm HIGH
Net weight: 43Kg
Others: Thermal cut-off protection, manual focus adjustable
TECHNICAL DATA
TROUBLESHOOTING
KEEPING THE PROJECTOR CLEAN
