OmniSistem PR Orland Follow Spot - Manual (Page 2)

2/8
Orland Follow manual.doc
SAFE USAGE OF THE PROJECTOR 3
OPERATION 4
FITTING THE LAMP 5
MASTER/SLAVE SYNCHRO MODE 5
MAINTENANCE 6
KEEPING THE PROJECTOR CLEAN 7
TROUBLESHOOTING 7
TECHNICAL DATA 7
Please note that as part of our ongoing commitment to continuous product development, specifications are subject to change
without notice. Whilst every care is taken in the preparation of this manual we reserve the right to change specifications in the
course of product improvement. The publishers cannot be held responsible for the accuracy of the information herein, or any
consequence arising from them.
Every apparatus has been tested completely and packed properly by the manufacturer. Please make sure the packing and / or
the apparatus is in good condition before your installation and use. Should there be any damage caused by transportation,
consult your dealer and do not use the apparatus. But any damage caused by improper use will not be assumed by the
manufacturer and / or dealer.
THESE ITEMS ARE PACKED TOGETHER WITH THE PROJECTOR
5-PIN XLR plug(1PCS)
5-PIN XLR socket(1PCS)
3-Foot bracket (1 SET) (Optional)
This manual (1 PCS)
Thank you for purchasing the product Orland Follow, PR-1211.
This product manual contains important information about the safe installation and use of this
projector. Please read and follow these instructions carefully and keep this manual in a safe place
for future reference.
The Orland Follow is an innovative projector with an elegant housing made from high quality
aluminiun-alloy and steel with an epoxy paint finish. The Orland Follow complies to CE norms and
standards and uses international protocol DMX-512.
The Orland Follow uses HMI 1200W lamp and high quality optical systems which produce bright
and beautiful light beam, and it can continuously adjust the brightness from 0% to 100% via the
mechanical device. The Orland Follow features effects of strobe, soft light beam, mixing colours
and rainbow, and the projector may be used in stand-alone mode or synchro mode, so it is
suitable for use in TV station, disc, singing and dancing stage, night club and so on.
The Orland Follow is controlled by dedicated manual controller, and the operation is easy and
convenient. The unit is installed on the 3-foot bracket, and the angle and the height of the body
are easy to be adjusted.
The projector has protection devices of auto thermal cut-off and lamp power cut-off in case you
directly open the cover for lamp replacement before switching off the general switch.
ACCESSORIES
INDEX
INTRODUCTION
