Moon-halogen manual.doc 11/14
PROBLEM RESOURCE
The projector does not start Check the fuse on the socket is blown or not.
Check if the lamp is good or not.
The projector switches on but does not
answer to commands Check the projector is correctly configurated.
Check the XLR cable is good.
The projector only functions
intermittently Check the fan is working and not dirty.
The beam appears dim Check the lamp is not at the end of its life.
Check the optics are clean.
Projection with halo Carefully clean the lamp and optical group lenses.
Defecting projection Check the lenses are not broken.
Remove dust or grease stored on lenses.
Power supply: 230V AC 50Hz
Optional: 240V, 220V, 200V, 120V, 100V AC 50/60Hz
Power consumption: 280W at 220V
Lamp: EVC 24V/250W
Manufacturers Rated Lamp Life: 300 hours
Channels: 7 channels
Signal: Standard DMX 512
Control mode: Sound activation, Auto programmes, Controller
Running mode: Stand-Alone mode, Master/Slave synchro mode, Controller mode
Colours: 9 dichroic colours + white and rainbow effect
Gobos: 7 interchangeable rotating gobos + clear
Shutter/strobe: Mechanical shutter for blackout and strobe effect,
Adjustable from 1 ~ 8 F.P.S.
Beam coverage: 13.6
Movement: Pan movement 175 / Tilt movement 80
Net weight: 9.4kg
Others: Lamp brightness adjustable / Auto thermal cut-off /
Manual adjustable focus
TROUBLESHOOTING
TECHNICAL DATA
