Appendix 3
TERMINATOR CONNECTION
PR LIGHTING LTD.
Add: Yingbin Road, Dashi, Panyu, Guangzhou ,China
Post-Code 511430
TEL 020 8478 1888
FAX 020 8478 6023
P/N: 321010073
Rev: 21:04:2003
DMX TERMINATOR CONNECTION
Connect a 120
Ω
(OHM) resistor
across pins 2 and 3 in an XLR plug
and insert into the DMX Out socket
on the last unit in the chain.
120
Ω
