avoid the reflection during the DMX-512 signal transmission. (Please refer to
appendix 3: terminator connection)
mirage PR-2014H adopts 3-pin XLR plug/socket. If you use 5-pin XLR
plug/socket, you should use a convertible cable as shown in appendix 2.
In order to fully use mirage PR-2014H, we suggest you select our controller
which is designed specially for MANTIS series luminaires.
Channels
mirage PR-2014H has 3 channels and uses DMX 512 protocol. (Please see
the following table)
CHANNEL DESCRIPTION
1 Gobo
2 Colour
3 Lamp ON/OFF
Maintenance
Position the apparatus in a dry place. Avoid places where there is high
humidity.
Interval use may prolong the life of the apparatus.
To obtain adequate ventilation and optimal lighting output, the fan, ventilation
net and lens must be cleaned regularly.
Please do not use any organic solvent, e.g. alcohol, to clean the housing of
the apparatus.
Important Statement
The apparatus is tested and packed properly by the manufacturer.
Please make sure the packing and / or the apparatus in good conditions before
installation and use. Any loss caused by improper use will not be assumed by
the manufacturer and / or dealers.
This manual is subject to change without notification.
