DMX CONTROL CHANNEL FUNCTIONS
MANTIS has 3 channels and uses DMX 512 control protocol. They are listed in the following table.
CHANNEL
DMX 512 VALUE
DESCRIPTION
0 - 18
Black-out
19 - 37
White / Clear
38 - 56
Red / Gobo 1
57 - 75
Blue / Gobo 2
76 - 94
Light blue / Gobo 3
95 - 113
Pink / Gobo 4
114 - 132
Green / Gobo 5
133 - 151
Purple / Gobo 6
152 - 170
Yellow / Gobo 7
171 - 179
(Red, Green, Yellow, Blue) / Gobo 8
1
COLOUR /
GOBO
180 - 255
Colour/gobo wheel rotate in clockwise or anti-clockwise
direction from slow to fast
0
Stop
1 - 80
Rotate in clockwise direction from fast to slow
81 - 173
Stop
2
REFLECTOR
DISC
ROTATION
174 - 255
Rotate in anti-clockwise direction from slow to fast
3 DIMMER
0 - 255
Lamp brightness adjust from dark to bright
TABLE FOR SETTING ADDRESS OF DIP SWITCHES
The following table lists the setting codes of the address of the DIP switches, and the luminaires are
from No.1 to No. 85. Each DIP switch has 10 switches with the number of #1, #2, #3, #4, #5, #6, #7,
#8, #9 and #10.
(For the MANTIS, set all #9 and #10 switches on the “OFF”.)
In the table, “0” means the switch is on the “OFF”, and “1” on the “ON”.
For example, if you want to look up the address setting of the No. 10 luminaire, you will find the No.
10 luminaire row (#1, #2, #3, #4) with the codes of “0”, “0”, “1”, “1” and column (#5, #6, #7, #8) with the
codes of “1”, “0”, “0” , “0”. So set the #3, #4 and #5 switches on the “ON”, and set the #1, #2, #6, #7,
#8, #9 and #10 switches on the “OFF”.
#8
0
0
0
0
0
0
0
0
1
1
1
1
1
1
1
1
Setting Table of
Address Switches #7
0
0
0
0
1
1
1
1
0
0
0
0
1
1
1
1
#6
0
0
1
1
0
0
1
1
0
0
1
1
0
0
1
1
0=OFF
1=ON
#5
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
#1
#2
#3
#4
0
0
0
0
6
22
38
54
70
1
0
0
0
1
17
33
49
65
81
0
1
0
0
12
28
44
60
76
1
1
0
0
7
23
39
55
71
0
0
1
0
2
18
34
50
66
82
1
0
1
0
13
29
45
61
77
0
1
1
0
8
24
40
56
72
1
1
1
0
3
19
35
51
67
83
0
0
0
1
14
30
46
62
78
1
0
0
1
9
25
41
57
73
0
1
0
1
4
20
36
52
68
84
1
1
0
1
15
31
47
63
79
0
0
1
1
10
26
42
58
74
1
0
1
1
5
21
37
53
69
85
0
1
1
1
16
32
48
64
80
1
1
1
1
11
27
43
59
75
