COMPONENT ORDER CODES
NAME PART NO. REMARK
TRANSFORMER 040030020 AC 230V50Hz
THERMOSTAT 190010054 95 /10A
FAN 030060008 DC12V
LAMP 100040001 EVC 24V/250W
(COLOR/GOBO) MOTOR 030040001 17HS0504
(MIRROR) MOTOR 030030019 DC 12V GM350090F015A
OPTICAL-COUPLE 171000008 MOC3022
U1 230040016 MICROPROCESSOR 2
U2 170170012 BUS CHIP FOR
RECEIVING/TRANSMITTING
U3 170040009 TTL CIRCUIT CHIP
U4 170050002 ARITHMETIC AMPLIFIER CHIP
U5 170170038 DRIVER CHIP
U6 230040018 MICROPROCESSOR 1
U7 230040019 SPECIAL IC
