Mantis manual.doc 2/12
SAFE USAGE OF THE PROJECTOR 3
INSTALLING THE PROJECTOR 4
FITTING THE LAMP 4
POWER SUPPLY – MAINS 5
OPERATION 5
XLR CONNECTORS AND TERMINATOR 5
STAND-ALONE MODE 6
MASTER/SLAVE SYNCHRO MODE 7
CONTROLLER MODE - DMX OPERATION 7
MAINTENANCE 9
KEEPING THE PROJECTOR CLEAN 9
TROUBLE SHOOTING 9
TECHNICAL DATA 10
ELECTRICAL DIAGRAM 11
Please note that as part of our ongoing commitment to continuous product development, specifications are subject to change
without notice. Whilst every care is taken in the preparation of this manual we reserve the right to change specifications in the
course of product improvement. The publishers cannot be held responsible for the accuracy of the information herein, or any
consequence arising from them.
Every apparatus is tested completely and packed properly by the manufacturer. Please make sure the packing and / or the
apparatus is in good condition before your installation and use. Should there be any damage caused by transportation, consult
your dealer and do not use the apparatus. But any damage caused by improper use will not be assumed by the manufacturer
and / or dealer.
THESE ITEMS ARE PACKED TOGETHER WITH THE PROJECTOR
Mounting Bracket (1 PCS)
M8 knobs for mounting bracket (2 PCS)
Safety cord (1 PCS)
Power-cord (1 PCS)
XLR plug (1 PCS)
XLR socket (1 PCS)
This manual (1 PCS)
Thank you for purchasing the product MANTIS, PR-2021H.
This product manual contains important information about the safe installation and use of this projector.
Please read and follow these instructions carefully and keep this manual in a safe place for future
reference.
MANTIS adopts advanced procedure of design and manufacturing. The figure of housing is elegant,
lovable and portable, which features its special character compared with conventional luminaire. It is
convenient to hang the unit and the angle of the body is easy to be adjusted, and the projector even
can be carried by hand.
MANTIS complies to CE norms and standards and uses international protocol DMX 512. It can be
controlled by sound, auto programmes or a controller, and can be used as a stand-alone unit or linked
with each other for multi-units or linked to a controller, so it is suitable for many different applications.
MANTIS series have 5 types of products for your selection: PR-2021H-1, PR-2021H-2, PR-2021H-3,
PR-2021H-4 and PR-2021H-5. (There are some differences among them. For detail please refer to
“Technical Data” section)
You can get rainbow effect when the colour/gobo wheel rotates quickly. The projecctor has a device of
auto thermal cut-off. And the projector will switch off the lamp automatically after about 30 seconds of
shutter, so it can effectively prolong the life of the lamp.
ACCESSORIES
INDEX
INTRODUCTION
