Shortcut: Press “up” and “down” for three seconds to flip the display directly.
Brand Show
With this function you can show or hide the brand name on the display during menu
operation, but still show it after reset.
Key Lock
With this function you can lock the keys of the Control Board to e.g. prevent menu tampering. If this function is
activated, the keys will be automatically locked as soon as you exit the menu. In order to deactivate or
temporarily deactivate the key lock function, press UP­DOWN­LEFT­RIGHT­ENTER to regain access to the
menu commands.
Users
User mode
With this function you can create user defined channel orders.
Edit User
With this function you can adjust the preset user defined channel order.
Calibration
With this function, you can calibrate and adjust the effect wheels to their correct positions. The password for
this function is “050“.
Fixture ID
RDM
With this function you can call up various submenus via RDM.
This device is RDM ready. RDM stands for "Remote Device Management" and makes remote control of devices
connected to the DMX bus possible. ANSI E1.20­2006 by ESTA specifies the RDM standard as an extension of
the DMX­512 protocol.
Manual settings like adjusting the DMX starting address are no longer needed. This is especially useful when the
device is installed in a remote area.
RDM is integrated in DMX without influencing the connections. The RDM data is transmitted via the standard XLR
poles 1 and 2 — new DMX cables are not necessary. RDM ready and conventional DMX devices can be operated
in one DMX line. The RDM protocol sends its own packages in the DMX­512 data feed and does not influence
conventional devices.
If DMX splitters are used and RDM control is to be used, these splitters must support RDM.
The number and type of RDM parameters depend on the (optional) RDM controller being used.
RDM Parameter ID's (Slot 21­22) Value
Category _Network Management
DISC_UNIQUE_BRANCH 0x0001
DISC_MUTE 0x0002
DISC_UN_MUTE 0x0003
Category ­RDM Information
SUPPORTED_PARAMETERS 0x0050
PARAMETER_DESCRIPTION 0x0051
20 of 26
