Control Board
The Control Board offers several features. You can simply set the starting address, run the pre­programmed
program, or perform a reset.
Main Menu
The main menu is accessed by pressing Enter until the display is lit. Browse through the menu by pressing the
arrow buttons (up, down, left, right). Press Enter in order to select the desired menu. You can change the
selection by pressing the arrow buttons. Press Enter in order to confirm selection, then exit back to the main
menu to save changes. The functions provided are described in the following sections.
① = Basic Reload ② = Program Reload ③ = Private Reload Default settings are listed in bold.
MENU SUBMENU SELECTION FUNCTION
Connect DMX Address ① XXX DMX Address Setting
Light Lamp On/Off On/Off Lamp On or Off
Automatic On/Off Lamp On or Off with
Power On
DMX Control On/Off DMX Control On or Off
Max Temperature ① 80~139°C, 120°C
176~282°F, 248°F Set internal
temperature to shut the
unit off. (Activates after
5 minutes.)
Lamp Adjust ① Pan…... Adjust Value
Information Time Info Current XXXX (Hours)
Fixture Life XXXX (Hours) Boot Time
Total Run Time
Lamp Info Voltage
Current
Power HID Lamp Information
Temperature Near Lamp Temp Temperature Sensors
Fans Speed Near Lamp Fan Fan Speed Sensors
Channel Value Pan…... Display Channel Value
Error Message Pan, Tilt…... Channel Errors
Fixture Model [Model & Brand] Display Model & Brand
16 of 26
