Connection with the Mains
Connect the device to the power source with the enclosed power supply cable.
The configuration of the connection cables is as follows:
Cable Pin International
Brown Live L
Blue Neutral N
Yellow/Green Ground
Ground needs to be connected!
If the device will be directly connected with the local power supply network, a disconnection switch with a
minimum opening of 3mm at every pole has to be included in the permanent electrical installation.
The device must only be connected with an electric installation carried out in compliance with the IEC standards.
The electric installation must be equipped with a Residual Current Device (RCD) with a maximum fault current of
30mA.
Device must not be connected to dimming packs.
The device is equipped with a lockable power input connector. Plug in the power cord and turn it to the right until it
locks. Plug the power cord into a grounded electrical outlet that matches the rated voltage of the machine.
OPERATION
With the power switch, you can switch the device on and off.
After being connected to the power supply, the fixture starts running. During the reset, the motors are trimmed and
the device is ready to use.
Stand Alone operation
In the Stand Alone mode, the device can be used without controller.
Disconnect the fixture from the controller and call the internal program.
Please refer to the instructions under Control Board.
DMX­Controlled operation
You can control the projectors individually via your DMX controller. Every DMX channel has a different occupation
with different features. The individual channels and their features are listed under DMX protocol.
Addressing
The Control Board allows you to assign the DMX starting address, which is defined as the first channel from which
the fixture will respond to the controller.
If you set, for example, the address to channel 20, a fixture in 18 channel mode would use channels 20 to 38
for control.
Please be sure that you don’t have any overlapping channels in order to control each fixture correctly and
independently from any other fixture on the DMX chain. If several fixtures are addressed similarly, they will work
synchronically.
Press the Up/Down buttons for setting the desired starting address. Now you can start operating the fixture via
your lighting controller.
