3. Press the Enter button to confirm.



Hibernation ­ Power Standby Mode
With this function you can put the device in the power standby mode. This function will be automatically activated



































after a predefined period of time of no DMX activity. In standby mode the lamp/LEDs and all motors will power































down if no DMX signal is sent to the fixture for a period of e. g. 15 minutes (can be user defined). The fixture will





































automatically reset and return to normal operation once a DMX signal is sent.



Backlight
With this function you can shut off the display after 2 to 60 minutes.



Flip Display
With this function you can flip the display by 180° for a better view when the fixture is installed upside down.
Shortcut: Press “up” and “down” for three seconds to flip the display directly.



Brand Show
With this function you can show or hide the brand name on the display during menu

































operation, but still show it after reset.



Key Lock
With this function you can lock the keys of the Control Board to e.g. prevent menu tampering. If this function is
activated, the keys will be automatically locked as soon as you exit the menu. In order to deactivate or
temporarily deactivate the key lock function, press UP­DOWN­LEFT­RIGHT­ENTER  to regain access to the
menu commands.

Users

User mode
With this function you can create user defined channel orders.



Edit User
With this function you can adjust the preset user defined channel order.



Calibration
With this function, you can calibrate and adjust the effect wheels to their correct positions. The password for
this function is “050“.



Fixture ID



RDM

With this function you can call up various submenus via RDM.



This device is RDM ready. RDM stands for "Remote Device Management" and makes remote control of devices
connected to the DMX bus possible. ANSI E1.20­2006 by ESTA specifies the RDM standard as an extension of
the DMX­512 protocol.



Manual settings like adjusting the DMX starting address are no longer needed. This is especially useful when the
device is installed in a remote area.



RDM is integrated in DMX without influencing the connections. The RDM data is transmitted via the standard XLR
poles 1 and 2 — new DMX cables are not necessary. RDM ready and conventional DMX devices can be operated
in one DMX line. The RDM protocol sends its own packages in the DMX­512 data feed and does not influence
conventional devices.



If DMX splitters are used and RDM control is to be used, these splitters must support RDM.



The number and type of RDM parameters depend on the (optional) RDM controller being used.


RDM Parameter ID's (Slot 21­22)

Value

21 of 27
