OPERATION
DANGER: Hazard of Fire. Keep combustible materi-
als and temperature sensitive fabrics at least 4”
away from front of cover or above cover. WARNING: Users should install adequate back-up
controls and safety devices with their electric
heating equipment. Where the consequences of
failure may be severe, back-up controls are essen-
tial. Although the safety of the installation is the
responsibility of the user, Chromalox will be glad to
make equipment recommendations.
MAINTENANCE
WARNING: Hazard of Severe Shock. Disconnect all
power to heater before servicing or replacing
heaters.
1. Following long periods of idleness, heater should be vacuumed
before start-up, to remove accumulated combustible particles
which will incinerate causing smoking and consequent wall
discoloration.
2. If heater is located in areas of heavy traffic, furnish suitable
heater guard (wall mounted pipe rail in front of case, for exam-
ple) to prevent damage to heater.
RENEWAL PARTS IDENTIFICATION
Model Volts Watts Heating Element Switch Thermostat Overtemp Cut-Out Front Case
120 250 118-553632-001 292-511857-001 300-049198-001 300-053610-001 080-511673-001
ICH-18025
208 250 118-553632-022 292-511857-002 300-049198-002 300-053610-001 080-511673-001
240 250 118-553632-023 292-511857-002 300-049198-002 300-053610-001 080-511673-001
277 250 118-553632-024 292-511857-001 300-049198-001 300-053610-001 080-511673-001
120 500 118-553632-002 292-511857-001 300-049198-001 300-053610-001 080-511673-002
ICH-28050
208 500 118-553632-003 292-511857-002 300-049198-002 300-053610-001 080-511673-002
240 500 118-553632-004 292-511857-002 300-049198-002 300-053610-001 080-511673-002
277 500 118-553632-005 292-511857-001 300-049198-001 300-053610-001 080-511673-002
120 750 118-553632-006 292-511857-001 300-049198-001 300-053610-001 080-511673-003
ICH-38075
208 750 118-553632-007 292-511857-002 300-049198-002 300-053610-001 080-511673-003
240 750 118-553632-008 292-511857-002 300-049198-002 300-053610-001 080-511673-003
277 750 118-553632-009 292-511857-001 300-049198-001 300-053610-001 080-511673-003
120 1000 118-553632-010 292-511857-001 300-049198-001 300-053610-002 080-511673-004
ICH-48100
208 1000 118-553632-011 292-511857-002 300-049198-002 300-053610-002 080-511673-004
240 1000 118-553632-012 292-511857-002 300-049198-002 300-053610-002 080-511673-004
277 1000 118-553632-013 292-511857-001 300-049198-001 300-053610-002 080-511673-004
120 1250 118-553632-014 292-511857-001 300-049198-001 300-053610-002 080-511673-005
ICH-60125
208 1250 118-553632-015 292-511857-002 300-049198-002 300-053610-002 080-511673-005
240 1250 118-553632-016 292-511857-002 300-049198-002 300-053610-002 080-511673-005
277 1250 118-553632-017 292-511857-001 300-049198-001 300-053610-002 080-511673-005
120 1500 118-553632-018 292-511857-001 300-049198-001 300-053610-002 080-511673-006
ICH-72150
208 1500 118-553632-019 292-511857-002 300-049198-002 300-053610-002 080-511673-006
240 1500 118-553632-020 292-511857-002 300-049198-002 300-053610-002 080-511673-006
277 1500 118-553632-021 292-511857-001 300-049198-001 300-053610-002 080-511673-006
