NORAC UC4+BC+JD8 Update User Manual
Page 10

3.1
Target Modification and Alignment (Active Roll™ Only)
It is very important that the rods be installed on the right hand side of the sprayer.
If the brackets are installed on the left hand side, they must be moved.
1.
Ensure the sprayer chassis and booms are leveled and the center section is approximately 4
feet above the ground. A ladder or step will be required for this part of the installation.
Figure 8: Roll Control™ Items
Figure 9: Typical Roll Control™ Install
Frame Target
(B07)
Spring Target
(B08)
Sensor Bracket
(B11)
Remove the
Rubber Bumper
Frame
Target
Roll
Control
Frame
Sprayer Parallel Lift Frame
Sensor
Bracket
Roll
Sensor
Spring
Target
Boom Centre
Frame
