3.2 Hydraulic Plumbing
1. Remove all plastic plugs from the NORAC expansion valve block (V01).
2. Insert the orifice (F05) into the “B” port of the expansion block.
3. Install the 6MB 6MJ fitting (F04) into the “B” port of the expansion block.
4. Install the 6MBP plug (F03) into the “A” port of the expansion block.
5. If the valve block is not already installed on the sprayer, install it as outlined in the UC4.5
Spray Height Control installation manual.
6. Attach hose H01 to the “B” port on the expansion block. Route the free end of the hose
to the Summers valve block.
7. Tee in H01 to the existing main lift line on the Summers valve block, using the tee fitting
(F02).
Ensure no hydraulic components will interfere with any sprayer parts or be pulled
tight at any time.
