NORAC UC4.5-SM3 - Manual (Page 6)

3
2.2 List of Parts
The following tables list the Summers main lift and enhanced stability kit (SM3) specific parts of
the NORAC UC4.5 system. This kit is to be used when installing the proportional main lift
option with existing Summers installations.
Item Part Number Name Quantity
B05 44706-01 KIT CABLE TIE BLACK 10 PCS 21 IN 150 PCS 7.5 IN 1
C07 43220-01 CABLE UC5 NETWORK 14 AWG 1M 2
C17 44658-45D CABLE UC4 VALVE MAIN DT 1
E04 43741 UC5 ROLL SENSOR VER. 2 1
E05 43750 UC5 ULTRASONIC SENSOR 1
E10 43760 UC5 NETWORK COUPLER 3-WAY 1
E12 43764 UC5 NETWORK COUPLER 2-WAY 1
H01 44863-01 HOSE ASSEMBLY 122R2-06 36 IN L 6FJX 6FJX 1
H10 44865-50 HYDRAULICS FITTING KIT - SM3 1
M01 UC4.5-SM3-INST MANUAL INSTALLATION UC4.5 SUMMERS MAIN LIFT AND ENHANCED STABILITY 1
V01 44962D VALVE ASSEMBLY EXPANSION DPOC PROP DT 4 BOLT 1
