8
3.6 Alternate Cabling
Some Rogator sprayers may require different cabling depending on the connectors used near
the valve block. Please refer to Table 1 and Table 3 for ordering alternate cabling from
NORAC.
Table 1: Alternate Interface Cabling Available from NORAC
Item
Replaced
Description Connector Type Norac Part #
C12 Interface Cable Weatherpack 44658-21
C12 Interface Cable Metripack 280 44658-32
C12 Interface Cable Deutsch DT 44658-24
If the sprayer uses a bypass/ jam valve, choose from the Bypass/ Jam Cabling options in Table 2
and Table 3 for ordering bypass cabling from NORAC.
Table 2: Bypass/Jam Cabling Available from NORAC
Item No. Description Connector Type Norac Part #
C16 Bypass Cable Weatherpack 44658-34
C16 Bypass Cable Metripack 280 44658-33
C16 Bypass Cable Deutsch DT 44658-27
Table 3: Illustrations of Connector Types
Weatherpack
Metripack 280
Deutsch DT
