Mytek Protools-HD DIO Card – User Manual
12. Use SOURCE TO DIGITAL OUT and SOURCE TO
ANALOG OUT buttons to set desired signal flow in the
system.
✔
Use SOURCE TO DIGITAL OUT button to select
which audio signals are sent from the 8X192 ADDA
converter to the Pro Tools system and converter’s
digital outputs.
✔
Choose the signal transmitted to converter’s analog
output by pressing SOURCE TO ANALOG OUT
button.
13.
In Setup > I/O Setup configure the routing according to
your needs, keeping in mind that 8X192 ADDA
converter has eight channels.
Setup > I/O Setup
