Mytek Protools-HD DIO Card – User Manual
8. Open Setup > Hardware Setup and check:
✔
Are 8X192 ADDA Mytek Digital converters properly
detected as 192 I/O?
✔
Are signals input and output of each converter
assigned in the Input and Output tab?
✗
If not, turn off the Pro Tools application and
converters and check the connections of clock signals
between converters as well as the connections
between DIO-HD cards and with computer.
Setup > Hardware Setup
9.
If the hardware configuration was changed, open Setup >
Hardware Setup and press Set To Default.
10.
Set Clock Source as Internal.
11. Open or create new project with a chosen frequency.
✔
LED indicating operation at the chosen frequency
should be lit on the front panel.
✗
If LED is not lit or another frequency is indicated,
check the connection between DIO-HD cards and
with the computer.
