MOOER Micro Buffer - Manual

1. TRUE BYPASS Footswitch:
Push down the footswitch to toggle
between on and bypass status.
2. ON/OFF LED:
3. DC IN Power Jack:
For power supply, use a 9-volt
DC regulated AC adapter (plug
polarity is positive on the barrel
and negative in the center).
4. INPUT Jack:
1/4” mono audio jack, for connecting
guitar.
5. OUTPUT Jack:
1/4” mono audio jack, outputs the signal.
* Disclaimer: Any specification’s update won't be amended in this manual.
Shows the on/off status of Micro Buffer,
when the LED is lit the
effect is engaged.
Full metal shell
Very small and compact design
True bypass switch
DC 9V adapter power supply
Main Features
PLEASE READ CAREFULLY BEFORE PROCEEDING
Power Supply
Connections
Always turn off the power of this and all other equipment before connecting or
disconnecting, this will help prevent malfunction and / or damage to other devices.
Also make sure to disconnect all connection cables and the power cord before
moving this unit.
Cleaning
Clean only with a soft, dry cloth. If necessary, slightly moisten the cloth.
Do not use abrasive cleanser, cleaning alcohol, paint thinners, wax, solvents,
cleaning fluids, or chemical-impregnated wiping cloths.
Interference with other electrical devices
Radios and televisions placed nearby may experience reception interference.
Operate this unit at a suitable distance from radios and televisions.
Location
To avoid deformation, discoloration, or other serious damage, do not expose
this unit to the following conditions:
Direct sunlight Heat sources
Magnetic fields Extreme temperature or humidity
Excessive dusty or dirty location High humidity or moisture
Strong vibrations or shocks
Please connect the designated AC adapter to an AC outlet of the correct voltage.
Please be sure to use only an AC adapter which supplies 9V (±10%) DC, center
minus. The maximum working voltage shall not exceed 12V, otherwise may be
dangerous equipment damage, fire or other problems.
Unplug the AC power adapter when not using or during electrical storms.
Precautions
Buffer Pedal
Accurate copy of the input signal frequency and removal of unconven-
tional signal frequency, which perfectly output the original signal to
the next pedal, resulting in the original musical sound
5
4
3
7 6
8
8. BOOST Knob: Add up to +6dB of gain to buffered signal.
6. LOW CUT Switch:
When the switch is on, cuts bottom
end frequencies of buffered signal.
7. HIGH CUT Switch:
When the switch is on, cuts top end
frequencies of buffered signal.
Low Cut Frequency: 140Hz
High Cut Frequency: 4.5kHz
Input: 1/4” monaural jack (impedance: 1M Ohms)
Output: 1/4” monaural jack (impedance: 120 Ohms)
Power Requirements: AC adapter 9V DC (center minus plug),
recommended to use Mooer Micro Power
Current Draw: 20 mA
Dimensions: 93.5mm (D) × 42mm (W) × 52mm (H)
Weight: 145g
Accessories: Owner’s Manual
FCC certification
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
This device may not cause harmful interference.
This device must accept any interference received, including interference
that may cause undesired operation.
Equipped with a High-cut & Low-cut switch and a Boost knob, making
the Micro Buffer feature richer and more convenient to use
