Page 4
Chart A - Kit Selection
Disconnect
Tipover
Tipover
Single Phase
Three Phase
Model
Kit
Kit
w/Ground Fault
Cord Set
Cord Set
STAR-02A-11-PC
NA
NA
NA
STAR-02A-81-P
NA
NA
NA
PCN 295670
NA
STAR-02A-21-P
NA
NA
NA
PCN 295670
NA
STAR-02A-71-P
NA
NA
NA
PCN 295670
NA
STAR-02A-41-P
NA
NA
NA
PCN 295670
NA
STAR-02A-61-P
NA
NA
NA
PCN 295670
NA
STAR-05A-81-P
NA
NA
NA
PCN 295662
NA
STAR-05A-21-P
NA
NA
NA
PCN 295662
NA
STAR-05A-71-P
NA
NA
NA
PCN 295670
NA
STAR-05A-41-P
NA
NA
NA
PCN 295670
NA
STAR-05A-61-P
NA
NA
NA
PCN 295670
NA
STAR-06A-83-P
PCN 340662
PCN 340670
PCN 340726
PCN 295443
PCN 295435
STAR-06A-23-P
PCN 340662
PCN 340689
PCN 340734
PCN 295443
PCN 295435
STAR-06A-71-P
PCN 340662
PCN 340697
PCN 340742
PCN 295443
NA
STAR-06A-43-P
PCN 340662
PCN 340700
PCN 340750
PCN 295662
PCN 295427
STAR-06A-63-P
PCN 340662
PCN 340718
PCN 340769
PCN 295662
PCN 295427
STAR-1A4-83-P
PCN 340662
PCN 340670
PCN 340726
NA
PCN 295494
STAR-14A-23-P
PCN 340662
PCN 340689
PCN 340734
NA
PCN 295478
STAR-14A-71-P
PCN 340662
PCN 340697
PCN 340742
PCN 295486
NA
STAR-14A-43-P
PCN 340662
PCN 340700
PCN 340750
PCN 295443
PCN 295435
STAR-14A-63-P
PCN 340662
PCN 340718
PCN 340769
PCN 295443
PCN 295427
Chart B - Plug Selection
OPTIONAL ACCESSORIES
Comes w/cord & plug
—
Fits Cable Dia.
Plug Type
Model
Description
Volts
Amps
Configuration
NEMA #
ANSI #
.385”-.780”
Locking
PGL-15-20
3 Pole, 4 Wire
250
20
L15-20
C73.85
.385”-.780”
Locking
PGL-15-30
3 Pole, 4 Wire
250
30
L15-30
C73.86
.595”-1.150”
Locking
PGL-16-30
3 Pole, 4 Wire
480
30
L16-30
C73.88
.595”-1.150”
Locking
PGL-17-30
3 Pole, 4 Wire
600
30
L17-30
C73.89
.750”-1.125”
Locking
PGL-3763C
2 Pole, 4 Wire
600
50
—
—
.750”-1.125”
Locking
PGL-3765C
3 Pole, 4 Wire
600
50
—
—
.625”-1.187”
Non Locking
PGN-6-50
2 Pole, 3 Wire
250
50
6-50
C73.53
.390”-.775”
Non Locking
PGN-15-20
3 Pole, 4 Wire
250
20
15-20
C73.59
.750”-1.250”
Non Locking
PGN-15-50
3 Pole, 4 Wire
250
50
15-50
C73.61
The above plugs are designed to be used with specific ranges of cable diameters. If not used with Chromalox Cable Kits, check cable man-
ufacturers cable diameter to be sure plug fits selected cable.
