3.1.3 MAFE Interface Configuration
R/W
ADDR
07
06
05
04
03
02
01
00
Write
0x01 DYSEN
NSLAVE[2:0]
MSIDEN
MSID
SCK32
Write
0x02
TMEN
ENLPW
SPOS
HC
The MAFE interface must be properly configured by the user before the user can properly access the
device. The device is powered up out of reset in a default state that may not match the final desired
MAFE interface operating mode. The user must be able to operate in this default mode out of reset to
configure the MAFE interface registers for proper long term stable operation. Refer to the
73M1822/73M1922 Data Sheet (Section 8) for instructions on configuring the MAFE interface for optimal
operation.
3.1.4 Clock and Sample Rate Management
The clock and sample rate are managed through a series of registers in the host side device. Refer to
the 73M1822/73M1922 Data Sheet (Section 7) for instructions on configuring the device registers for
optimal operation in various clock and sample rates. Please note the Barrier and PLL can be expected to
temporarily become out of Sync and Lock respectively during a Clock or Sample Rate change. Please
note that, unlike and barrier sync loss due to an error condition, the user can assume the line side
registers will preserve their contents during a sample rate change
R/W ADDR
07
06
05
04
03
02
01
00
RW
0x08
PSEQ7
PSEQ6
PSEQ5
PSEQ4
PSEQ3
PSEQ2
PSEQ1
PSEQ0
RW
0x09
PRST2
PRST1
PRST0
PDVSR4
PDVSR3 PDVSR2 PDVSR1 PDVSR0
RW
0x0A
ICHP3
ICHP2
ICHP1
ICHP0
Reserved KVCOH2 KVCOH1 KVCOH0
RW
0x0B
Reserved NDVSR6 NDVSR5
NDVSR4
NDVSR3 NDVSR2 NDVSR1 NDVSR0
RW
0x0C
NSEQ7
NSEQ6
NSEQ5
NSEQ4
NSEQ3
NSEQ2
NSEQ1
NSEQ0
RW
0x0D
LOKDET
SLHS
Reserved Reserved CHNGFS
NRST2
NRST1
NRST0
The temporary variables defined in this procedure are:
VAL1 = System appropriate values for RG08
RG0D
Begin
1. Write RG08
RG0D = VAL1.
2. Write CHNGFS = 1
3. Wait 10ms
4. Read RG03, RG0D.
END
Start
Configure
Crystal/PLL
registers
Write CHNGFS
Read
RG03,RG0D
End
