Santa Fe (MAXREFDES5#) ZedBoard Quick Start Guide
6
4. Procedure
1. Connect the Santa Fe board to the JA1 port of a ZedBoard as shown in Figure 1 .
2. Power up the ZedBoard by connecting its corresponding AC-to-DC power
adaptor and sliding the SW8 switch on the ZedBoard to the ON position.
3. Download the latest “all design files” RD5V02_00.ZIP file at
www.maximintegrated.com/AN5561 . All files available for download are
available at the bottom of the page.
4. Extract the RD5V02_00.ZIP file to a directory on your PC. The location is
arbitrary but the maximum path length limitation in Windows (260 characters)
should not be exceeded.
In addition, the Xilinx tools require the path to not contain any spaces.
C:\Do Not Use Spaces In The Path\RD5V02_00.ZIP
(This path has spaces.)
For the purposes of this document, it will be C:\designs\maxim\RD5V02_00\.
See
Appendix A: Project Structure and Key Filenames in this document for
the project structure and key filenames.
