Vermont Castings, Majestic Products: DVR33
10004920
3a. Pilot Assembly SIT Top Convertible RN 10002264
3b. Pilot Assembly SIT Top Convertible RP 10002265
4a. Pilot Assembly SIT Top Convertible EN 10002387
4b. Pilot Assembly SIT Top Convertible EP 10002388
5a. Pilot Assembly PSE RN 10001741
5b. Pilot Assembly PSE RP 10001742
6. Pilot SIT Top Convertible 10002266
7. Pilot PSE (with Cable and Electrode) 10001824
* Pilot Orifice SIT NG 10002268
* Pilot Orifice SIT LP 10002269
* Pilot Orifice PSE NG 10001822
* Pilot Orifice PSE LP 10001823
8. Pilot Hood SIT Top Convertible 10002385
9. Thermocouple SIT 53373
10. Thermocouple PSE 10001825
11. Thermopile 51827
12. Ignitor Electrode with Cable, SIT RN/RP 10001297
13. Ignitor Electrode SIT EN/EP 52465
14. Cable Ignitor SIT EN/EP 10000696
15. Piezo Ignitor Honeywell Gas Valve 20000062
16. Piezo Ignitor SIT820 Gas Valve 52464
17. Pilot Tube with Fittings SIT 10001296
18. Pilot Tube with Fittings PSE 10003279
* Manifold Tube with Fittings 57318
19. Flexible Gas Line with ON/OFF Valve 20002500
20a. Honeywell Gas Control Valve, RN 10001782
20b. Honeywell Gas Control Valve, RP 10001759
21a. SIT820 Gas Control Valve RN 52677
21b. SIT820 Gas Control Valve RP 52678
22a. SIT822 Gas Control Valve EN 57884
22b. SIT822 Gas Control Valve EP 57883
23. Sensing Electrode (w/ Cable) EN/EP 57885
24. Transformer 24V EN/EP 7522409
25. Ignition Module Honeywell EN/EP 20000005
* Wire Harness Honeywell EN/EP 10001979
* Fan Assy (FK-24 option) ZA1100
26. Fan with Bracket (from FK-24 Option) 54103
* Electric Cord (from FK-24 Option) 51865
27. Fan Temperature Sensor (from FK-24 Option) 51704
28. Fan Speed Control (from FK-24 Option) 51738
29. Knob Fan Speed Control (from FK-24 Option) 51882
30. Sensor w/ Box and Wire (from FK-24 Option) 10004210
* Fan Assembly (FK-12 Option) ZA1110
31. Window Frame Assembly (no glass) 10001803
DVR33
(continued) (Items marked ‘*’ are not shown in the parts illustration.)
Ref. Description DVR33
