Vermont Castings, Majestic Products: DVR33
10004920
40
41
42
39
19
30
29
28
27
25
24
Vermont Castings, Majestic Products reserves the right to make changes in design, materials, specifications, prices and discontinue colors and
products at any time, without notice.
DVR33
(Items marked with ‘*’ are not shown in the parts illustration.)
Ref.
Description
DVR33
1.
Log Set (complete)
10004921
1a.
Log - Front/Rear Left
10004929 (A33)
1b.
Log - Rear Right
10004925 (A34)
1c.
Log - Front Right
10004928 (A35)
1d.
Log - Front Center
10004927 (A36)
*
Lava Rock 1 lb. package
10001454
*
Lava Rock Burner Package
57897
2.
Burner Housing Assembly, NG & LP
10004901
2a.
Ceramic Tile (Single)
57803
*
Orifice Burner NG and LP
See the rating plate for orifice specifications
4920 DVR33 parts2
