B. Interrupt Request Lines ( IRQ )
There are a total of 15 IRQ lines available on the Industrial CPU Card. Peripheral
devices use interrupt request lines to notify CPU for the service required. The
following table shows the IRQ used by the devices on the Industrial CPU Card.
Level Function
IRQ0 System Timer
IRQ1 Keyboard
IRQ3 Serial Port#2
IRQ4 Serial Port#1
IRQ5 Reserved
IRQ6 Reserved
IRQ7 Parallel Port#1
IRQ8 Real Time Clock
IRQ9 ACPI
IRQ10 Serial Port#4 & Serial Port#6
IRQ11 Serial Port#3 & Serial Port#5
IRQ12 PS/2 Mouse
IRQ13 Reserved
IRQ14 Primary IDE
IRQ15 Secondary IDE
